Produktname
K2-MED
Info
Number of keys: | ....................... | 88 |
Protection: | ....................... | IP68 |
Activation force: | ....................... | 1,2 N |
Interface | ....................... | PS/2, USB |
Size: | ....................... | 290 x 134 x 13 mm |
Operation temperature: | ....................... | -20 °C to +70 °C |
Merkliste
Technical specification
Bezeichnung | Angabe |
---|---|
Switching technology: | Carbon-on-Gold contact |
Number of keys: | 88 |
Protection: | IP68 (NEMA 4, 4X) - submersible |
Key travel: | 1,25 mm |
Activation force: | 1,2 N |
Life: | approx. 2 Mio. operations |
Chassis: | Desktop |
Interface: | PS/2, USB |
Power: | 12mA@5V |
Size: | 290 x 134 x 13 mm |
Operation temperature: | -20 °C to +70 °C |
Humidity: | to 100% |
Shock: | 3x11 ms pulses (50g) each axes |
Vibration: | 0,04g/Hz, 20Hz-2kHz, 3 hours |
Certifications: | CE; FCC Class15, Part B |
Features
- 88 keys
- Complete protection against dust and liquids according IP68 (submersible)
- Low profile key design for easy and efficient cleaning
- Washable, no seams or crevices
- Low profile key design for easy and efficient cleaning
- Resistant against most common detergents and disinfection materials
- Sterilized in seconds, no need for expensive sterilization methods
- Ergonomically low profile chassis
- Silent low noise typing
- Low force and precise feedback key technology
- MS Windows keys
- USB-, PS/2-Combiinterface
Downloads
Ordering information
Part number | Product name | Features |
---|---|---|
PS00510 | K2-MED-USB-GER | German layout |
PS00511 | K2-MED-USB-US | US layout |
PS00513 | K2-MED-USB-CH | Swiss layout |
Additional layouts available on request! |
Branche
Industrieautomation, Medizin, Lebensmittelverarbeitung
